NQYYS眼药水电子烟油灌装加塞旋盖机

产品详情Product Details

贷款用途与详细资料/Brief Introduction:

该机可用到于2-30ML多种板材的一个圆形扁形朔料或窗户塑料瓶子的眼麻醉药分装、电子厂烟油等小服用量分装.该机由高精密度轴承度数系统可以保证度数等分盘分析上塞上盖;下载加访问速度轴承机械传动链可以保证旋盖头的起降;恒扭力旋盖;蠕动消化泵剂量分装;触控屏屏的控制.无瓶不分装,没加内塞,外盖.具分析正确,机械传动链市场平稳,保证饮料瓶盖,剂量准.方法简单化等优势。This machine is mainly available to fill eye-drop into various round and flat plastic or glass bottles with the range from 2--30ml.High precision cam provides a regular plate to position, cork and cap; accelerating cam makes capping heads going up and down ;constant turning arm screws caps; creepage pump measures filling volume; and touch screen controls all action. No bottle no filling and no capping. If there is no plug in the bottle, it must not cap until having been detected plug in the bottle. The machine enjoys high position accuracy, stable driving, precise dosage, and simple operation and also protects bottle caps.




性能/Characteristic:

◆微我的电脑选用、装量准确、实际操作简单方便。Man-machine dialogue system setting,visual convenient operation ,accurate filling level。◆服务器主机带速可进行无级变速交流变频可控硅调压。the mainframe running speed is stepless frequency conversion.◆生孩子量主动一定量控制。the product quantity can be controlled. ◆种出现问题的温馨提示工作(如低大气压力。无分装、无内塞等)。Multi-failure prompt function (such as infrabar, no filling and no inserting plug etc).    ◆定时停电特点,对任意行列发生接连无罐装、无内塞状况可定时停电。Automatic stop function, if there is no filling, no inner plug in any rail, it may stop automatically.


技术设备运作/Main Technical Parameters:

不适用尺寸规格Filling Volume

2-30ml

生产销售技能Productivity

30-60瓶/分  70-100瓶/分

30-60bottles/min  70-100bottles/min

包装精密度较Filling Precision

≤±1%

电源适配器 Power Supply

380V/50Hz

旋(轧)盖率Capping Rate:

≥99%

自主上塞率Stoppering rate

≥99%

汽源Air Supply

1.3 m3/h    0.4-0.8Mpa

工作电压 Power

2.0 kw

器机净重量Weight

550 kg

形态尺码Dimension

1800*1000*1500mm
