妙用与详细介绍/Brief Introduction：

终端服务器所利用了唯一性三通管罐装阀，支持于水剂和膏霜类厂品的罐装，特殊对高黏度原材料管理（如浓酱、灯笼椒酱、番茄酱、种衣剂、微乳剂、自主隐藏剂等）的治疗效果对比显著的，且要求高。终端服务器所利用了PLC可源程序掌握，配上6寸大触碰屏人与机器画质软件，推行自主进瓶，自主罐装，自主出瓶，电，汽动元部分均所利用了国际联盟企业品牌，确认了不错的重量和坚持下去稳定可靠的功能。本机结构的简单易行，实际操作利于，是内地满意的涉及高黏度原材料管理的罐装机。终端服务器搭载了以避免渗漏与拉丝工艺机的罐装闷头，确认罐装完后无渗漏，无拉丝工艺机。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

优点/Characteristic：

◆操作软件设备——利用三凌PLC操作软件设备，灌装线使用量随即稍微调整。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆运营的用户接面——6寸大彩屏手触式运营的用户接面，形象直观方便、平安牢靠Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆特点键表整改——开料有防渗漏控制系统，可表明原辅材料的特点必备下潜分装特点键表。（此特点键表不错备选）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电嚣部件——均所采用新国际口碑好企业品牌，事关产品的健康可靠性、准确性高；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机械厂构件——机械设备构件均按照一流304不锈不锈钢材料钢板网作,假如有须得打交道原料也可以按照316L另扣费用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆筛选检验——实时时间筛选，对工作中产能客观展现。Counting test, real-time, intuitive reflect the yield of work.◆分装检测工具——无瓶不灌、瓶数太少不灌Bottle filling test - no bottle no filling, not enough◆维修保养现状——机器具备GMP需求，可便捷拆下、家电清洗维修保养。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆对换标准——换掉包装标准时，只需要简单调节，不累搞掂。Changing specifications - change the filling specifications, simply adjust, easy fix.◆安全加配——加配了安全结构，使服务器的操控氛围更为环保健康清洁。（此安全加配就能够加配）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

能力参数表/technical parameters：

罐装头数The number of filling head	8头（ಞ能选4、6、8、10、18个装灌头）8 head (optional 4, 6, 8, 10, 12 filling head)
可用于瓶径 Applicable bottles Drive	Ф33-Ф100 mm
计量检测定位精度measure precision	±1%
罐装存储空间Canned capacity	150-1000ml
生育本事Production Capacity	2400-4000瓶/小时候2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
